The DVT-100 DC Voltage Transducer is designed to convert a 1-100 DC Voltage input to either a 4-20mA output or a voltage standard output that is proportional to the input. It is also perfect for solar-string voltage monitoring. The DC Voltage Transducer provides effective and safe isolation between the input and output.
DVT-100
Features:
- Primary voltage DVT-100: 100-1000 Vdc
- Output 4-20mA, 0-1Vdc, 0-5Vdc
- Accuracy: 1% over range
- Linearity: 0.5% over range
- Response time: 10.0 mSec
- Working Range: 0-120%
- Overload: 150% continuous
- Temperature: -30 degrees C to 70 degrees C operating
- Humidity: 90% operating
- Isolation: 4.5KV, 1 Minute
- Supply voltage: 15-48 Vdc
